| Camera Module-Image Sensor | 1/2.5" progressive scan CMOS-Min. Illumination: Color: 0.005 Lux @(F1.6, AGC ON) / B/W: 0.001Lux @(F1.6, AGC ON) / 0 Lux with IR-White Balance: Auto/Manual/ATW (Auto-tracking White Balance)/Indoor/Outdoor/Fluorescent Lamp/Sodium Lamp-Gain: Auto/Manual-Shutter Time: 50Hz: 1/1 s to 1/30,000 s / 60Hz: 1/1 s to 1/30,000 s-Day & Night: IR Cut Filter-Digital Zoom: 16×-Privacy Mask: 24 programmable privacy masks-Focus Mode: Auto/Semi-automatic/Manual-WDR: 120 dB (not supported by full frame rate)Lens-Focal Length: 4.8 mm to 120 mm, 25× optical zoom-Zoom Speed: Approx. 3.6 s (optical lens, wide-tele)-Field of View: Horizontal field of view: 59.5° to 2.6° (Wide-Tele) Vertical field of view: 35.7° to 1.5° (Wide-Tele) Diagonal field of view: 66.6 to 3.0° (Wide-Tele)-Working Distance: 10 mm to 1500 mm (wide-tele)-Aperture Range: F1.6 to F2.8IR-IR Distance: 100 m-Smart IR: SupportPTZ-Movement Range (Pan): 360° endless-Pan Speed: Configurable, from 0.1°/s to 80°/s / Preset speed: 80°/s-Movement Range (Tilt): From -15° to 90° (auto-flip)-Tilt Speed: Configurable, from 0.1°/s to 80°/s / Preset Speed: 80°/s-Proportional Zoom: Support-Presets: 300-Patrol Scan: 8 patrols, up to 32 presets for each patrol-Pattern Scan: 4 pattern scans, record time over 10 minutes for each scan-Power-off Memory: Support-Park Action: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan-3D Positioning: Support-PTZ Position Display: Support-Preset Freezing: Support-Scheduled Task: Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan/Dome Reboot/Dome Adjust/Aux OutputNetwork-Network Storage: Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/ CIPS), ANR-Protocols: IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour-API: Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party Management Platform-Simultaneous Live View: Up to 20 channels-User/Host: Up to 32 users / 3 levels: Administrator, Operator and User-Security Measures: User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering-Client: iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect-Web Browser: IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51Interface-Network Interface: 1 RJ45 10 M/100 M Ethernet, PoE+ (802.3 at, class4)General-Power: 12 VDC and PoE+ (802.3 at, class4) / Max.: 18 W (Max. 7 W for IR)-Working Temperature: -30°C to 65°C (-22°F to 149°F)-Working Humidity: ≤ 90%-Protection Level: IP66 Standard, TVS 4000V Lightning Protection, Surge Protection and Voltage Transient Protection-Material: ADC 12, PC, PC+10% GF-Dimensions: Φ 164.5 mm × 290 mm (Φ 6.48" × 11.42")-Weight: Approx. 2 kg (4.41 lb) |
|---|
